Customized Seamless Stainless Steel Welded Pipe Tube 316 316L 2205 2200mm

Name: Customized Seamless Stainless Steel Welded Pipe Tube 316 316L 2205 2200mm
Brand: ZHE HENG
Price: 1000 USD

Wholesale Customized Seamless Stainless Steel Welded Pipe Tube 316 316L 2205 2200mm from china suppliers

Brand Name : ZHE HENG

Model Number : ASTM316,ASTM316L

Certification : BV, PED, ISO9001

Place of Origin : Wenzhou,China

MOQ : 500 kg

Price : $1000-4200/Ton

Payment Terms : L/C, T/T, D/P, D/A

Supply Ability : 1000+

Delivery Time : 30-45 work days

Packaging Details : As to clients' requirements，Wooden Cases，Bundle Packin

Term Name : Stainless Seamless Steel Pipe

Material Grade : ASTM316,ASTM316L

Shape : Rounde Pipe,Square Pipe,Rectangular Pipe

Technique : Cold Rolled,Pickling

Length : 2200mm Or 13000mm

Size : As per requirement

Welding Line Type : Seamless,Welded

Contact Now

Product Description

Overview:

ASTM 316 stainless steel pipe is metastable austenitic stainless steel, so he has a complete austenitic structure when in full solution conditions. If the ASTM316 stainless steel pipe is processed through cold deformation, the strength and hardness of the steel can be improved, and enough plasticity and toughness will be retained. In addition to the above description, ASTM316 stainless steel pipe also has good rust resistance under atmospheric conditions.

Specification:

Outside Diameter	OD 0.28-1219mm
Thickness	0.08-100mm
Seamless Stainless Steel Pipes	1/8“NB to 32“NB IN
Production Process	Cold Drawn,Bright Anneal.etc
Type	Seamless,welded
Surface	Pickling,Bright；
Price Item	EXW,FOB,CNF,CIF etc
Application	Pulp and paper equipment Heat exchangers, dyeing equipment, pipes, materials for the exterior of buildings in coastal areas, etc
Ends:	Beveled or plain end, square cut, burr free

Stainless Steel Seamless Pipe Chemical Component:

Chemical Composition about stainless steel pipe
Grade	C ≤	Si ≤	Mn ≤	P ≤	S ≤	Ni ≤	Cr ≤
316L	0.035	0.75	2	0.045	0.03	10.00-15.00	16.00-18.00
316	0.08	1	2	0.045	0.03	10.00-14.00	16.00-18.00

Size table:

Seamless stainless steel pipes

WALL THCKNESS FOR STAINLESS STEEL PIPE &T UBE (ASME B36.10 & B36.19)
DNmm	DNin	φmm	SCH5S	SCH10S	SCH40S	STD	Sch40	Sch60	Sch80s	XS	Sch80	Sch120	Sch140	Sch160	XXS
6	1/8	10.3		1.24	1.73	1.73	1.73		2.41	2.41	2.41
8	1/4	13.7		1.65	2.24	2.24	2.24		3.02	3.02	3.02
10	3/8	17.1		1.65	2.31	2.31	2.31		3.2	3.2	3.2
15	1/2	21.3	1.65	2.11	2.77	2.77	2.77		3.73	3.73	3.73			4.78	7.47
20	3/4	26.7	1.65	2.11	2.87	2.87	2.87		3.91	3.91	3.91			5.56	7.82
25	1	33.4	1.65	2.77	3.38	3.38	3.38		4.55	4.55	4.55			6.35	9.09
32	1 1/4	42.2	1.65	2.77	3.56	3.56	3.56		4.85	4.85	4.85			6.35	9.7
40	1 1/2	48.3	1.65	2.77	3.68	3.68	3.68		5.08	5.08	5.08			7.14	10.15
50	2	60.3	1.65	2.77	3.91	3.91	3.91		5.54	5.54	5.54			8.74	11.07
65	2 1/2	76	2.11	3.05	5.16	5.16	5.16		7.01	7.01	7.01			9.53	14.02
80	3	88.9	2.11	3.05	5.49	5.49	5.49		7.62	7.62	7.62			11.13	15.24
90	3 1/2	101.6	2.11	3.05	5.74	5.74	5.74		8.08	8.08	8.08
100	4	114.3	2.11	3.05	6.02	6.02	6.02		8.56	8.56	8.56	11.13		13.49	17.12
125	5	141.3	2.77	3.4	6.55	6.55	6.55		9.53	9.53	9.53	12.7		15.88	19.05
150	6	168.3	2.77	3.4	7.11	7.11	7.11		10.97	10.97	10.97	14.27		18.26	21.95
200	8	219.1	2.77	3.76	8.18	8.18	8.18	10.31	12.7	12.7	12.7	18.26	20.62	23.01	22.23
250	10	273	3.4	4.19	9.27	9.27	9.27	12.7	12.7	12.7	15.09	21.44	25.4	28.58	25.4
300	12	323.8	3.96	4.57	9.53	9.53	10.31	14.27	12.7	12.7	17.48	25.4	28.58	33.32	25.4
350	14	355.6	3.96	4.78		9.53	11.13	15.09		12.7	19.05	27.79	31.75	35.71
400	16	406.4	4.19	4.78		9.53	12.7	16.66		12.7	21.44	30.96	36.53	40.49
450	18	457	4.19	4.78		9.53	14.27	19.05		12.7	23.83	34.93	39.67	45.24
500	20	508	4.78	5.54		9.53	15.09	20.62		12.7	26.19	38.1	44.45	50.01
550	22	559	4.78	5.54		9.53		22.23		12.7	28.58	41.28	47.63	53.98
600	24	610	5.54	6.35		9.53	17.48	24.61		12.7	30.96	46.02	52.37	59.54
650	26	660				9.53				12.7
700	28	711				9.53				12.7
750	30	762	6.35	7.92		9.53				12.7
800	32	813				9.53	17.48			12.7

Conforms to ANSI B36.19 and ANSI B36.10 standards

Customized Seamless Stainless Steel Welded Pipe Tube 316 316L 2205 2200mm

FAQ:
Q: Are you a manufacturer or merely a trader?
A: We are group of companies and owned manufacturer bases and trading company. We specialized in special steel which include alloy structural steel and carbon steel and stainless steel, etc. All material are with high quality and competitive price.
Q: How do you guarantee the quality of your product?
A: Firstly, we can provide the certificates from the third party, such as TUV, CE, if you need. Secondly, we have a complete set of inspection system and every process is checked by QC. Quality is the lifeline of enterprise survival.
Q: Delivery time?
A: We have ready stock for most of material grades in our warehouse. If the material don't have stock, the delivery lead time is about 5-30 days after receiving your prepayment or firm order.
Q: What is the payment term?
A: T/T or L/C.
Q: Can you provide a sample for our testing before confirm the order?
A: Yes. We can provide sample to you for approval before you place an order to us. Free sample is available if we have stock.
Q: Can we visit your company and factory?
A: Yes, warmly welcome! We can book the hotel for you before you come to China and arrange our driver to our airport to pick you up when you come.
